Incoloy 800/800H/800HT Nut
Incoloy 800 / 800H / 800HT Nut Manufacturer in Vadodara, India
UNS N08810 Nuts, Incoloy 800 Nuts, Incoloy 800H Nut Fastener, Inconel Alloy 800 Nuts, Alloy 800 Nuts, ASTM F2281 Incoloy 800HT Nuts, Incoloy Alloy 800H Nuts Dealer, Incoloy Alloy 800 Nut, Incoloy® Alloy 800 Nuts, Incoloy 800 Nuts Manufacturer in Vadodara, India.
GreatBolt Industries is a well-known industry in manufacturing, supplying and exporting the high quality of quantitative ranges of Inconel 800 Nut. These are provided in different standards and specifications to the national and international clients to meet all their desires. These UNS N08810 nuts are developed by using superior quality of grade and considering product quality standards.
Inconel 800 is referred to as Alloy 800 and UNS N08800 also. Alloy Inconel 800 is the nickel, chromium, and iron stabilized alloy that is having enough resistance to oxidation and carburization at greater temperature and moderate strength. This grade is useful for the greater temperature equipment into the petrochemical sector because this alloy doesn’t form an embrittling sigma phase after getting exposed for a long duration at a temperature ranging from 1200 Deg F. Another thing about this alloy is that it having commendable resistance ability to chloride SCC. This alloy is widely used for the process piping, heating-element sheathing, heat exchangers, carburizing equipment, process piping and in nuclear steam generator tube.
Inconel alloy is austenitic chromium and nickel-based super-alloy. It is the oxidation and corrosion-resistant metal that is very well suited for the services in the atmosphere that subjected to high pressure and high heat. When it is heated, it forms a stable, thick and passivating oxide layer that is protecting the surface from more attacks. This alloy retains its strength over the ranges of temperature and is attractive for greater temperature application wherein the aluminum and steel could succumb to a creep resulting from the thermally induced crystal vacancies. The high-temperature strength of this metal is developed by a solid solution strengthening, based upon alloy.
Our Inconel 800H Nut is having few properties to offer namely corrosion-proof, rust-free, high hardness, longevity, precise dimensions, and good surface finishes making it an ideal selection.
Incoloy 800H Lock Nut, Incoloy 800 Hex Nut, DIN 1.4876 Incoloy Nuts, Incoloy 800 Nylock Nuts, Incoloy Alloy 800H Heavy Hex Nut, Incoloy Alloy 800HT Weld Nut, Incoloy 800 Dome Nuts Exporter in India.
Incoloy Alloy 800 Nut Stockholder, Incoloy Alloy 800 Hex Nuts, Incoloy N08810 Nuts, Inconel 1.4958 Nuts, Incoloy 800HT Square Nuts, Incoloy 800H Flange Nut, Incoloy Alloy 800H Eye Nut Supplier in India.
When Inconel 800HT Nut is delivered to the global and local clients its documenting is done. We are offering copies of some documents like quality assurance plan, mill test certificates, heat-treating chart, radiography test report, etc.
The nuts are sending for the testing to assure high quality of product shipping. The tests done are IGC-PMI test, toughness test etc.
Incoloy Alloy 800 / 800H / 800HT Nuts Types
Incoloy 800 / 800H / 800HT Hex Nut
Incoloy 800 / 800H / 800HT Heavy Hex Nut
Incoloy 800 / 800H / 800HT Lock Nut
Incoloy 800 / 800H / 800HT Nylock Nut
Incoloy 800 / 800H / 800HT Weld Nut
Incoloy 800 / 800H / 800HT Dome Nut
Incoloy 800 / 800H / 800HT Flange Nut
Incoloy 800 / 800H / 800HT Square Nut
Incoloy 800 / 800H / 800HT Eye Nut
Incoloy 800 / 800H / 800HT Threaded Nut
Specification of Incoloy 800 / 800H / 800HT Nut
| Standard : | ASTM B425, ASME SB425, F2281 |
| Dimension : | ASTM,DIN, BS,GB, IS and all International Standards |
| Length : | 3 mm to 200 mm |
| Nut Size : | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Heat Treatment: | Annealing, Stress Relieving, Case Hardening, Quenching and Tempering. |
| Type : | Hex Nut, Heavy Hex Nut, Lock Nut, Nylock Nut, Weld Nut, Dome Nut, Flange Nut, Square Nut, Eye Nut etc. |
Other Properties of Incoloy 800 / 800H / 800HT Nut
Equivalent Grades for Incoloy 800 / 800H / 800HT Nuts
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800 |
1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32T |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | - | X8NiCrAlTi32-21 | XH32T |
Incoloy 800 / 800H / 800HT Nut Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 - 35.00 | 19.00 - 23.00 | 0.15 - 0.60 | 0.15 - 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 - 35.00 | 19.00 - 23.00 | 0.15 - 0.60 | 0.15 - 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 - 35.00 | 19.00 - 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
Mechanical Properties of Incoloy 800 / 800H / 800HT Nuts
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30% |
People also search for Incoloy 1.4876 Nut
Incoloy 800 flange nut, incoloy 800 din hex nut, incoloy alloy 800 heavy hex nut, incoloy alloy 800ht square nut, incoloy alloy 800 nuts suppliers in mumbai, a wide range of the incoloy 800h nuts price list, incoloy 800 nuts supplier in mumbai india, din 1.4876 nuts, incoloy 800h nuts dealer, uns n08811 nuts, incoloy alloy 800 heavy hex nuts suppliers in india, incoloy alloy 800 hex nut, incoloy 800 nuts distributors, incoloy alloy 800ht nuts, incoloy alloy 800h nylock nuts, incoloy 800ht nuts supplier in india, incoloy alloy 800h dome nut, incoloy alloy 800 nuts with metric fine thread exporter, incoloy alloy 800 nut manufacturer, incoloy alloy 800ht nuts suppiler in india, incoloy alloy 800ht threaded nuts supplier, astm b425 incoloy alloy 800h lock nut, incoloy alloy 800ht nuts price, incoloy alloy 800h square nut, incoloy alloy 800 eye nut with metric fine pitch thread, din weld nut, incoloy 800h nuts manufacturer in mumbai india.
Other Incoloy 800 / 800H / 800HT Nut Types
Wing Nut, Nylon Insert Lock Nut, Cap Nut, Hex Machine Nuts Small Pattern, Nylon Hex Jam Nut, Hex Finish Nut, Castle Nut, Break Away Nut, Slotted Hex Nut, Flange Serrated Nut, T-Nut, Hex Jam Nut, Keps-K Lock Nut, Hex Machine Nut, Prevailing Torque Lock (Stover) Nut, Coupling Nut, Structural Heavy Hex Nut, Shear Nut, Tri-Groove Nut, Knurled Thumb Nut.
Quality Assurance of Incoloy 800 / 800H / 800HT Nuts
Incoloy Alloy 800-800H-800HT Nuts are manufactured and controlled to international standards such as ASTM, ASME, BS, MSS, EN, DIN or WERKSTOFFE. Our products undergo stringent quality tests before they are dispatched.
