Incoloy 800 Bolts/Screw
Incoloy 800 Bolts / Screw Manufacturer in Vadodara, India
Incoloy 800 Bolts, Incoloy 800 Screws, Incoloy Alloy 800 Bolts, Inconel 800 Bolts, Inconel Alloy 800 Screws, Incoloy® Alloy 800 Screws, Incoloy 800H Bolts, Incoloy 800HT Screws, UNS N08800 Bolts Fastener Dealer, Incoloy N08810 Screws, Incoloy 800 Bolts Manufacturer in Vadodara, India.
GreatBolt Industries has firmly grown into a leading authority in the manufacture of the industrial fasteners, as standards ASME, UNI, ASTM, and DIN. The range of Inconel 800 Bolts/Screw involves indented foundation bolts and high strength friction grip bolts. All of the fasteners can be designed in various grades of good quality material and several coatings, galvanished, zinc, and many more.We produce high quality of products from several metals and metal alloys. We also offer ASTM grade nuts in different sizes and shapes.
A screw is a kind of fastener; on the other hand sometimes, it is similar to a bolt. It is made up of metal, and is generally identified by a helical ridge. Moreover, that is known by an external thread or say (male thread) or just a thread. A screw is a willing plane wrapped over a nail. Few screws threads are created to associate with a new thread, known as internal thread or female thread. The most general use of screws/bolts is to fixed objects together and to locate objects. There are so many features offered by Incoloy Alloy 800 Bolts/Screw and that are- High-temperature strength, Good oxidation resistance in various acidic environments, Excellent resistance to oxidation and good strength and carburization in exposure to high temperature, High creep rupture strength, Better resistance to different sulfur-containing atmospheres, etc.
ASTM F2281 Incoloy 800H Bolts-Screws, Inconel 800 Eye Bolt, Incoloy 800 Hex Bolt, Incoloy 800H Hexagonal Bolts, Incoloy 1.4876 Carriage Bolt, DIN 1.4958/1.4859 Flange Bolts, JIS NCF 800 Square Head Bolts Exporter, Incoloy 800/800H/800HT Bolts.
Incoloy 800 Hex Screws, Incoloy 800HT Heavy Hex Bolts, Incoloy 800H Coach Screw Stockholder, 800 Incoloy J-Bolt, Inconel 800 U-Bolt Supplier, 800 Inconel Alloy Fully Threaded Screws Supplier in India.
Inconel 800 Bolts/Screw is the more appropriate for applications that need good strength and stable structure at the time of prolonged exposure to colossal temperature. These bolts and screws are used in a diverse of industries, including high temperatures and oxidation environments. The nickel alloy series of Inconel 800 include Incoloy 800HT, 800H, 800. The Incoloy 800H provides better stress properties of rupture over 800. Incoloy 800HT offers much better rupture properties to ensure the best high-temperature properties.
Incoloy 800 Bolt and Screw Types
Incoloy 800 Hex
Bolt
Incoloy 800 Hex
Screw
Incoloy 800 Square Head Bolt
Incoloy 800 Coach Screw
Incoloy 800 U
Bolt
Incoloy 800 Carriage Bolt
Incoloy 800 Fully Threaded Screws
Incoloy 800 Eye
Bolt
Incoloy 800 Flange
Bolt
Incoloy 800 T Bolt /
J Bolt / L bolt
Specification of Incoloy 800 Bolt/Screw
| Standard : | ASTM F2281 |
| Dimension : | DIN, ASTM, BS and all International Standards |
| Size : | 3 mm to 200 mm |
| Bolt/Screw Size : | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Length | M02 to M33 |
| Heat Treatment : | Annealing, Stress Relieving, Case Hardening, Quenching and Tempering. |
| Type : | Hex Bolt/ Hex Screw, Square Head Bolt, U Bolt, Carriage Bolt, Eye Bolt, T Bolt/ J Bolt/ L bolt, Flange Bolt, Coach Screw etc. |
Other Properties of Incoloy 800 Bolt/Screw
Equivalent Grades for Incoloy 800 Bolt-Screw
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32T |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | - | X8NiCrAlTi32-21 | XH32T |
Incoloy 800 Bolt-Screws Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 - 35.00 | 19.00 - 23.00 | 0.15 - 0.60 | 0.15 - 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 - 35.00 | 19.00 - 23.00 | 0.15 - 0.60 | 0.15 - 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 - 35.00 | 19.00 - 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
Mechanical Properties of Incoloy 800 Bolts-Screws
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30% |
People also search for DIN 1.4876 Bolt/Screw
A wide range of the incoloy jis ncf 800 screws price list, incoloy 800 screws, incoloy 800h screws, incoloy 800ht bolts, incoloy 800 bolts, incoloy alloy 800 bolt and screws price, incoloy 800 bolt and screw distributors, incoloy 800 bolts supplier in mumbai, india, incoloy din 1.4876 hex bolt, 800 incoloy hex screw, incoloy n08800 square head bolt, incoloy 800 screw manufacturer in india, 800h incoloy screws with metric fine thread exporter, 800ht incoloy® alloy coach screws suppliers in india, astm f228 800 bolt screw, incoloy 800 carriage bolts, alloy n08810 eye bolt with metric fine pitch thread, din 1.4876 t-bolt, incoloy 1.4958/1.4859 j bolt, incoloy n08811 flange bolt, nickel alloy 800 l bolts, incoloy 800h fully threaded screws supplier, incoloy alloy 800 bolt and screws suppiler in india, 800 incoloy screws dealer, incoloy 800 bolts and screws suppliers in mumbai, incoloy 800 heavy hex bolt, incoloy alloy 800 bolt manufacturer, incoloy 800 screws supplier in india, incoloy 800 bolts manufacturer in vadodara, india.
Other Incoloy 800 Bolt Types
Step Bolt, Elevator Bolt, Head Plow Bolt, Lag Bolt, L bolt, T Bolt, Shoulder Bolt, Sex Bolts, Hanger Bolt, Square Bolts, Elevstor Bolt, 12 point Bolts, Socket Bolt, Anchor Bolt, Mushroom Head Square Neck Bolts, Foundation Bolts, Structural Bolts, T-Head Bolts, Plow Bolt, Draw Bolt, Step Bolt, Stove Bolt, Tap Bolt, Machine Bolt.
Other Incoloy 800 Screw Types
Socket Cap Screw, Deck Screws, Hex Lag Screws, Grub Screw, Set Screw, Wood Screws, Machine Screws, Concrete Screws, Thread Cutting Machine Screws, Fully threaded screws, Sheet metal screws, Self Drilling screws, Socket Screws, Masonry Screws, Sammys Screws, Anchor Screws, Panel Screws.
Quality Assurance of Incoloy 800 Bolt-Screw
Incoloy 800 Bolts and Screws are manufactured and controlled to international standards such as ASTM, ASME, BS, MSS, EN, DIN or WERKSTOFFE. Our products undergo stringent quality tests before they are dispatched.
